Material Data and mechanical properties of elastomers and polymers by means of leading optimization technologies

FEMCard Pro: Material Data Sets for highest Requirements

The material cards presented in the following are being identified by means of our professional testing and evaluation method. They are representing the most common combinations of experimental design and material model for elastomers and plastics. It can easily be taken into account individual customer requirements (eg different specimen geometries and experimental design). For all identified material parameters verifications are performed, which are clearly integrated into the final reports.



FEMCard Pro Hyperelastic
  • 3 tensile tests on perforated rectangular specimens
  • Material Model: Neo Hooke, Mooney-Rivlin
  • Optical measurement of displacement fields
  • Interpolation of displacement fields on corresponding FEM mesh
  • Identification of Material data sets
  • Price: 3150 EURO
  • Extra Cost for Ogden or Yeoh material model: 750 EURO
  • Additional charge for evaluation of 2nd - 4th material model: 950 EURO



FEMCard Pro Viscoelastic
  • 3 Loading and discharge Tests on perforated rectangular specimens
  • Material Model: Neo Hooke or Mooney-Rivlin with 3 or 4 relaxation moduli
  • Preconditioning of Specimens to minimize the mullins-effect
  • Optical measurement of displacement fields
  • Interpolation of displacement fields on corresponding FEM mesh
  • Identification of Material data sets
  • Price: 5150 EURO
  • Extra Cost for Ogden or Yeoh Material Model: 1200 EURO
  • Additional charge for evaluation of another viscoelastic material model: 1600 EURO



FEMCard Pro Mullins Add
  • 3 Loading and discharge Tests on perforated rectangular specimens
  • Material Model: All (Visco)-Hyperelastic + Mullins Effect
  • Optical measurement of displacement fields
  • Interpolation of displacement fields on corresponding FEM mesh
  • Identification of Material data sets
  • Extra Cost: 2950 EURO



FEMCard Pro Elastic-Plastic VM
  • 3 Loading and discharge Tests on perforated rectangular specimens
  • Material Model: Von Mises Plasticity with nonlinear isotropic hardening
  • Optical measurement of displacement fields
  • Interpolation of displacement fields on corresponding FEM mesh
  • Identification of Material data sets
  • Price: 3750 EURO



FEMCard Pro Elastic-Plastic DP
  • 3 Loading and discharge tensile Tests on perforated rectangular specimens
  • 3 Compression Tests on perforated cylindrical specimens
  • Material Model: Drucker-Prager Plasticity with nonlinear hardening
  • Optical measurement of displacement fields
  • Interpolation of displacement fields on corresponding FEM mesh
  • Identification of Material data sets
  • Price: On Demand



FEMCard Pro Damage
  • 3 Loading and discharge Tests on perforated rectangular specimens
  • Material Model: Gurson Damage Model
  • Optical measurement of displacement fields
  • Interpolation of displacement fields on corresponding FEM mesh
  • Identification of Material data sets
  • Price: On Demand



FEMCard Pro Crash
  • 2-3 tensile tests on perforated rectangular specimens at three different strain rates (e.g. 0.001 m/s, 1 m/s, 10 m/s)
  • Material Model: As requested (e.g. Johnson-Cook)
  • Optical measurement of displacement fields
  • Interpolation of displacement fields on corresponding FEM mesh
  • Identification of Material data sets
  • Price: On Demand





All displayed offers are non-binding. The prices are net excluding VAT of currently 19%. The terms and conditions for services of Parsolve GmbH, Düsseldorf, apply.
